ICEFREE VALLEY W/ DECORATIVE CLADDING

IceFree Valley w/ Decorative Cladding

IceFree Panel Products

Decorative icon

If you have problems with ice buildup on your roof during the winter months, finding the right product can make a big difference. Too much ice buildup on your roof can prevent snow from falling off; the resulting buildup can leak into your home and cause major damage. IceFree Valley Panel products seek to eliminate this problem by using heat to melt the snow and ice that forms in roof “valleys,” preventing ice dams and reducing buildup. Our selection of heated roof panels come in 3” or 6”-wide panels and multiple colors to match any roof. They are guaranteed to heat across their entire length. Your ice melt panels can be custom cut to fit the length of your roof’s valley. If you want to learn more about IceFree Valley and our other ice dam prevention products, don’t hesitate to reach out to our team today!

Specifications
Material Selection
Una-Clad Kynar 500 Painted Aluminum, 20 oz. Copper, CoreTen and other specialty options are available.

Color
Decorative Metal Cladding

Panel Size
Flat sheet panels are manufactured and sized to fit. Aluminum alloy channel is manufactured in 5 ft. lengths, cut to modify if necessary.

Heating Systems
Commercial Grade-Self Regulating Heat Cable (min. 5 Watt per foot in 100-130 VAC or 208-240 VAC). The IceFree Eave Panel - 8″ requires 2 feet of heat cable per foot of panel. Designed with 11mm or 14mm heat cables.

Components
Roof Panel, Transition Metal, Drip Edge, and Zee Metal; 3″ Aluminum Alloy Snap Loc Top; 3″ Aluminum Alloy Base Panel

Optional Items
Ambient and/or Moisture Sensor Controllers; Self-regulating heat cable for gutters and downspouts

Electrical Requirements
N.E.C. 426-28 requires 30mA ground fault circuit protection for snow and ice melting applications.

Attention: The IceFree Eave Panels in 8", 12" and 18" are not available in California.
IFV-03
IceFree Valley 3″ Thermal-Loc Architectural Decorative Cover; 3″ Aluminum Alloy Snap Loc Top; 3″ Aluminum Alloy Valley Base Panel

IFV-06
IceFree Valley 6″ Thermal-Loc Architectural Decorative Cover; 6″ Aluminum Alloy Snap Loc Top; 6″ Aluminum Alloy Utility Base Panel. Product shown with heat cable.

Painted Aluminum Cladding
IceFree Eave Panels are available with a decorative metal cladding. The Kynar 500 or Hylar 5000 cladding carries a 30-year warranty.
Roof Deicing Panels & Heated Roof Panels Colors

Call Now to Order IceFree Valley Panels
(801) 872-8800
